VTS
The Vehicle Traking Systems is a On-board tracking system that makes fleet management more powerful intelligent than ever. The fleet operator can monitor vehicles from a remote location using GPS satellite Technology ,through a vehicle tracking device. the vehicle transmits its location and other important data to a base station over a communication network.The base station receives the information in real time and displays it on a computerized map. with this information ,the fleet operator can take control of the fleet improving management decisions as events arise. information retrieved about the operation of the fleet can be summarized in system generated reports the should help in making more accurate descisions.
- Online position transimission to the base station at preset interval
- Monitoring the position and speed of the vehicle in real time on the Digital Map of the required region.
- Monitoring the position and speed of the vehicle in trems of the data in the format of the customizable reports.
- Facility to find a selected vehicle on the map.
- Facility to offline monitor the required vehicles in the selected time period.
- Centralized fleet database on a server.
- Transmission of current position on request from the base sever.
- Transmission of Login-Logout messages related to the operators ,either by the ‘Scan-card’ system or with the help of LCD or GTS provided with the hardware unit.
- Voice communication form the monitoring person at the base station.
- Storing the position related information in the H/W unit even when the network coverage area is not available and transimitting them after network gains its signal.
- Facility to update the map with new roads,rail lines,and tanks etc.
- Facility to add landmarks on the map
- Facility to find the distance covered by a particular vehicle in specified time period.
- Facility to find the vehicle down/idle time.
- Facility to find the nearest vehicle from a reqiured area.
- Assignment of vehicless and schedules to the operators.
- Facility to assign the login IDs and right for the monitoring person.
- Facility for mulitple users connected across internet to access the sytem.
- 32 Bit Cortex M3 Microcontroller
- External Flash for storage of data when GPRS is not available
- Multi Slot Class 12 GSM / GPRS Module
- 48 Channel GPS Receiver with -161 dBm gain
- Local and Over The Air (OTA)* Software Download
- Local and Over The Air (OTA) Configuration
- Secured Over The Air (OTA) Configuration
- Supports SMS; TCP; UDP and HTTP Communication Protocols
- Built in Geo-Fence Feature (10 Zones)
- Configurable Geo-Fence zones locally and Over The Air (OTA)
- GPS Odometer
- Wide DC Input Operating Voltage (9V to 36V)
- Main Power Reverse connection protection
- Main Power Over Voltage protection
- Built-In 7.4V / 900 mA Li-Ion Battery.
- Alert for low internal battery
- On demand vehicle location on GPRS enabled phones
- Remote device status monitoring
- Alert for GPS Antenna Tampering
- Alert for Main Power tampering
- Alerts for Over Speed, Harsh Acceleration* & Harsh Breaking
- Alert for Ignition and Engine On & Off *
- Alerts for IO Ports status
- SOS Switch supporting configurable message and 3 numbers
- GPS Communication
- L1 Frequency; 1575.42 MHz
- 48 Channels
- -160 dBm gain
- Horizontal Position Accuracy of lessthan 2.5 meters
- Operating Voltage
- 9 to 36V DC
- 7.4V/900 mA Li-Ion Internal Battery
- Mechanical
- IP65 ABS Plastic Enclosure
- Dimensions: 99 x 70 x 32 mm
- Wall / Table Mounting
- LED Indications
- LED for Main Power
- LED for Internal battery
- LED for GSM Network
- LED for GPS Network
- Environmental
- Operation Temperature: -20° to +65° C
- Storage Temperature: -25° to +75° C
- Humidity: 95% RH Non Condensing
- External Interfaces
- Power Cable with IOs
- RS-232 Serial Port
- SOS Switch
- Vehicle Surveillance System
- Fleet operators
- Public Transport Vehicles
- Emergency Vehicles
- Commercial Vehicles
- Infrastructure Vehicles
- School Transport Vehicles
- Personal Vehicles
- Security Apllications
